NFLOW

REFERENCE

Ballast Water Management System

Confirmation of TRO ballast water flow

in ballast pump

  • Client :  Marino B&C

  • Project by. Chicago Plan

  • Simulation Case : Fluid Flow Simulation in Drain

  • Background : To know whether the seawater is flowing normally to each sensor zone from TRO pipes.

  • Results

     1. Confirmation of discharged water in the pipe

          ( pressure / velocity )

     2. Setting standards on pipe size through poor drainage simulation

     3. Checking whether ejector emits sea water without any problems

NFLOW

REFERENCE

Road & Drain

Road Construction in Gigye-Andong4 National Highway

Korea Expressway Corporation

In the virtual reality space, the problems and improvement measures to weak drainage sections are identified through particle-based 3D fluid simulation based on execution drawing data. In the execution drawing section in Saemangeum-Jeonju expressway, the sections considered to have weak drainage are selected and divided into 9 sections for simulation.

Road Construction in Gigye-Andong4 National Highway

During heavy rainfall, rainwater flows into the village from mountains in the work construction work site between Gigye-Andong4, which flows into the river via the main waterway. In this case, the fluency of drainage during heavy rain in 25 and 30 years was reviewed as the flow property by using particle-based 3D fluid simulation.

Analysis of Drainage Flow by Simulation on Execution Drawing of Saemangeum-Jeonju Expressway

In the virtual reality space, the problems and improvement measures to weak drainage sections are identified through particle-based 3D fluid simulation based on execution drawing data. In the execution drawing section in Saemangeum-Jeonju expressway, the sections considered to have weak drainage are selected and divided into 9 sections for simulation.

Particle-based 3D Fluid Simulation in Hamyang-Ulsan Expressway Construction Work Site

During the execution drawing of zone 9 of Hamyang-Ulsan Expressway, the tunnel entrance / exit and cross drainage were divided into 3 sections and analyze by using 3D fluid simulation for verification of the propriety of design based on the sluice data (rainfall intensity, run-off coefficient and travel time).

3D Fluid Simulation of Underpass in Detour of National Highway in Suwon-si

Following the rapid increase in damage in underpass of roads during torrential downpours due to unusual weather, using numerical analysis, the changes in water level and depth as the hydraulic characteristic factors in underpass in Suwon-si were verified, and the data of flow inside underpass were analyzed into data for utilization in predicting and setting measures to changes in flux, velocity and hazardous sections.

3D Fluid Simulation in Waterlogging Situation following Collapse of Unjeong Reservoir

Through the virtual simulation of collapse of Unjeong Reservoir, the travel time to downstream, and waterlogging scope were predicted and analyzed during the collapse of reservoir to check
the scope of damage in downstream and utilize as the base data for establishing advance responsive system.

NFLOW

REFERENCE

Water Resource

3D Fluid Simulation on Execution drawing of Munbalje Reinforcement Work

Following the damage such as flooding of the embankment in part of the Munbalje section after localized torrential downpours, the flow attributes of the Munbalje section was comprehensively reviewed through numerical analysis. In order to reduce the flooding damage in Munbalje section in the downstream of Hangang River, which is a national river, the technological matters considering the dimensional functions of a river was simulated and reviewed to provide basic material for a reasonable and stable design.

OUR

REFERENCE

E8IGHT's REFERENCE

  • Application of waterlogging simulation from collapse of Unjeong Reservoir for Korea Rural Community Corporation

  • Application of 3D fluid simulation in Geomse District, Samramjin in Nakdonggang River for Busan Regional Construction and Management Office

  • Application of 3D fluid simulation in Gigye-Andong road construction work forBusan Regional Construction and Management Office

  • Application of 3D fluid simulation in Masong-Nusan road expansion work forSeoul Regional Construction and Management Office

  • Application of 3D fluid simulation in underpass of detour in Suwon-si forSeoul Regional Construction and Management Office

  • Application of 3D fluid simulation in execution design of Munbalje reinforcement work forSeoul Regional Construction and Management Office

  • Application of drainage design using 3D fluid simulation for Korea Expressway Corporation

  • Application of 3D fluid simulation in execution drawing of Gwnagju Sunhwan Expressway for Korea Expressway Corporation

  • Application of particle-based 3D fluid simulation in Saemangeum-Jeonju expressway construction work for Korea Expressway Corporation

  • Application of 3D fluid simulation in Saemangeum-Dongseo 2-Chuk road construction work for Korea Engineering Consultants Corp.

  • Application of particle-based 3D fluid simulation in Hamyang-Ulsan expressway construction work for Taeyoung Corp.

  • Establishment of NFLOW solution in disaster situation room for Natural Disaster Management Institute

  • Establishment of NFLOW solution for Korea Institute of Science and Technology Information

  • Establishment of NFLOW solution for Gachon University

  • Establishment of NFLOW solution for Gangneung-Wonju University

  • Establishment of NFLOW solution for Konkuk University

  • Establishment of NFLOW solution for Tongmyong University

  • Establishment of NFLOW solution for University of Seoul

  • Establishment of NFLOW solution for Hanbat National University

  • Establishment of NFLOW solution for Hanbat Taeyoung Corp.
